励磁用整流变压器
Excitation Rectifier Transformer
一、概述：
I. The Overview of Excitation Rectifier Transformer
为同步发电机提供励磁电源，而针对具体使用状况设计、制造的励磁整流变压器。
Excitation Rectifier Transformer is a kind of rectifier transformer that designed and manufactured to provide excitation source for synchronous generator.
二、用途：
II. The Function of Excitation Rectifier Transformer
主要用于同步发电机励磁电源。
Excitation Rectifier Transformer is mainly used in the excitation source of the synchronous generator.
三、结构特点：
III. The Structural Feature of Excitation Rectifier Transformer
励磁整流变压器主要用于发电机自复励磁系统中。我公司生产的励磁整流变压器具有很强的强励磁能力，通过在一、二次绕组间加放隔离屏敞层，可有效屏蔽变压器存在的寄生电容。并可抑制谐波对励磁系统的影响，励磁整流变压器的设计容量要大于实际铭牌容量。可有效抑制高次谐波的不利因素对变压器的影响
Excitation Rectifier Transformer is mainly used in the generator's self-excitation system. The Excitation Rectifier Transformer which is produced by our company has very strong excitation capacity. By adding put isolation layer between primary and secondary winding group, it can efficiently shield the parasitic capacitance existing in the transformer and restrain the harmonic wave's influence on excitation system. Excitation Rectifier Transformer's design capacity is greater than actual installed capacity and it can effectively restrain the influence that higher harmonics puts on the transformer.
四、技术参数
IV. The Technical Parameters of Excitation Rectifier Transformer
